Documentation

Click on photo to view full resolution picture

Decoded Broadcast Sheet for WS27L9G107248



Vehicle Order Number - 960172 - Ordered as a "Show Car"

G - St. Louis, MO manufacturing plant

Y16 - Sales Bank

E86 - 440ci HP engine 375HP

D32 - A727 3-Speed automatic transmission

D53 - 3.23:1 ratio 8 3/4" rearend

D91 - Sure-Grip rearend

T83 - F70 X 14 Red Side Wall tires

Y2 - Sunfire Yellow paint

V3X - Black convertible top

V8X - Black transverse tape stripe

A01 - Light Package

A62 - Rallye instrument cluster

B41 - Front disc brakes

B51 - Power brakes

C16 - Console

C31 - Head restraints - left & right

C55 - Bucket seats

C93 - Carpeting

F11 - 50 amp alternator

F25 - 70 amp hour HD battery with red caps

G11 - Tinted glass

G33 - Left hand outside chrome remote mirror

H51 - Air conditioning with front heater

J11 - Glove box lock

J15 - Cigar lighter

J25 - 3-Speed variable wipers

J31 - Dual horns

J41 - Pedal dress up

J55 - Undercoat with hood pad

L05 - Map/courtesy lamp

L11 - Glove box lamp

L15 - Ash receiver lamp

L25 - Trunk compartment lamp

L31 - Fender mounted turn signal lamps

L65 - Ignition switch lamp with timer

L72 - Headlamp on buzzer

M25 - Body sill mouldings (rocker panel)

M31 - Body belt mouldings (upper door)

M85 - Front & Rear bumper guards

N85 - Tachometer

P31 - Power windows

R11 - 2 watt AM Music Master radio

S15 - HD/Hemi suspension

S25 - HD shock absorbers front & rear (1")

S77 - Power steering

S81 - Woodgrain sport steering wheel

W21 - Magnum 500 Class II road wheel




Broadcast Sheet


Fender Tag & Rubbing


Original Title


Kelsey Hayes Recall Notice


Owner's Manual, Airtemp brochure & New Car Message
